Schuco Doors

ASS 39 PD.NI Panoramic Door

The Schüco ASS 39 PD.NI, non-insulated sliding system with panoramic design.

There is an absolute panoramic view, as the outer frames and door profiles are fully integrated into the building structure so that circumferentially almost no aluminum profile is visible. The innovative, detachable guide rail system allows easy access and removal of the roller track for cleaning or roller replacement foregoing the need to remove the sliding doors.

  • Concealed outer frame provides maximum transparency and light penetration
  • Door frame heights up to 3,300mm, Single or double glazed up to 32mm, Door panel weights up to 300kg
  • Wide selection of opening types based on double and triple-track outer frames
  • 90 degree clear corner opening option further adding to the design flexibility
  • Innovative guide rail system can be easily removed, maintained or replaced
  • Simple and fast cleaning and maintenance of the rollers without removing the door panel.

FWS-35 Series

Panoramic Design Window Series with a reduced face width of just 35mm, the Schüco FWS 35 PD Panorama Design façade offers extremely slim window façade design for streamlined architecture with maximum transparency.

 Benefits

  • Aluminium façade system solution with narrow face widths of just 35mm and frame depths up to 200mm (subject to structural requirements).
  • Suits all commercial, internal fit-out or architectural applications
  • All-glass corner for maximum transparency in the corner area
  • Schüco AWS window insert units including Schüco AWS 114 slimline parallel-opening sash
  • Externally glazed window system for on-site glazing of large glass panes.
  • Passive house-certified façade system with optimum thermal insulation properties offering Ucw values as low as 0.79 W/(m²K) reduces heating loads in winter and cooling loads in summer.

ASS-70 FD

Thermally Broken Bi-Fold Door

The Schüco ASS 70 FD folding/ sliding system is a thermally insulated construction, which offers the benefits of a wide choice of styles and a high level of transparency. Different requirements can be met. For example, the option of a flush threshold profile provides an easy-access entrance

  • Door panels heights up to 3,000mm and width up to 1,200mm
  • Single or double glazed up to 45mm
  • Door panel weights up to 100kg
  • Wide selection of opening types
  • Thermal insulation: U⒲ values of < 1.3 W/(m²K), depending on the design
  • Basic depth of 70mm
  • Narrow face widths from 120mm

ASS 70.HI Lift & Slide Door

Panoramic Design Window Series with a reduced face width of just 35mm, the Schüco FWS 35 PD Panorama Design façade offers extremely slim window façade design for streamlined architecture with maximum transparency.

 Benefits

  • Aluminium façade system solution with narrow face widths of just 35mm and frame depths up to 200mm (subject to structural requirements).
  • Suits all commercial, internal fit-out or architectural applications
  • All-glass corner for maximum transparency in the corner area
  • Schüco AWS window insert units including Schüco AWS 114 slimline parallel-opening sash
  • Externally glazed window system for on-site glazing of large glass panes.
  • Passive house-certified façade system with optimum thermal insulation properties offering Ucw values as low as 0.79 W/(m²K) reduces heating loads in winter and cooling loads in summer.

ADS 75 SimplySmart

The Schüco ADS 75 SimplySmart Aluminium Door System is a thermally broken entrance door system suitable for architectural homes and commercial projects.

  • 75mm deep thermally broken door suite
  • Suits all commercial, internal fit-out or architectural applications
  • Leaf height of up to 3,000 mm and maximum leaf weight up to 200 kg
  • Concealed or barrel hinge options
  • Patented hybrid insulator limits the bi-metallic effect
  • Use of centre gasket for increased air and water tightness values and reduced thermal transmittance
  • Ideal for combining with the Schüco Door Control System
  • Flat threshold option with automatic door seal
  • Can be integrated into Schüco façade systems and Schüco AWS window system
  • Based on standard Schüco system components
  • Supports single, double or triple glazing
  • Captive glazing wedge and internal glazing beads for easier and secure on-site glazing.
